3ft 120W 18000lm Linear LED High Bay
Feature
* High quality Meanwell/Tridonic power supply, AC100V~277V, 50/60Hz
input voltage, constant voltage or constant current output, quick
responds, no flicker, lightning protection, PFC function available,
0-10V, DALI intelligent dimming available;
* 100LPW Standard Version,120LPW Proline Version,160LPW Primeline
Version for option,CRI>83Ra,more sufficient;
* Suspended/Surface mounted/Adjustable installation for option;
* PIR sensor,Emergency,1-10V,DALI,Microwave sensor is available;
Advantage
* Excellent experience for distributors, wholesales and contractor
from Western Europe and Oceania;
* Our service and products are recognized from famous enterprises
such as Jalasoft, Mercedes-Benz, Rewe, Nahkauf, Hagebau,etc.
* OEM/ODM is available. We supply customized service for our
customers to meet their marketing;
* All our LED liminaires comply with CE, RoHS standard. TUV, ENEC,
VDE, SAA,C-Tick, LM79,LM80 listed for the leading products;
Application
* Train,Bus station
* Office
* Airport Hall
* Underground garage
| Model No. | DR-LB050-FG1XX | DR-LB100-FG2XX | DR-LB150-FG3XX | DR-LB200-FG4XX | DR-LB300-FG3XDX |
| System Watts/W | 50W | 100W | 150W | 200W | 300W |
| System Efficiency/LPW | 140LPW |
| Lumen Output/lm | 7.000±5% | 14.000±5% | 21.000±5% | 28.000±5% | 42.000±5% |
| Rated Input Voltage/V | AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional) |
| LEDs Light Source | SMD3030 |
| SDCM | <5 |
| CCT/K | 5000K for Standard (3000K/4000K/5700K/6500K Optional) |
| CRI/Ra | >70Ra (>80Ra for Option) |
| Power Factor | >0.95 |
| THD | <10% |
| Beam Angle(Optional) | 30°/60°/90°/30*70°/80*155/60*90° |
| UGR | <25 |
| Surge Protection | 6~10KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional |
| LED Driver | Meanwell ELG/HLG,Sosen |
| IP Rating | IP65 |
| Dimming(Optional) | 0/1-10V/DALI/Zigbee |
| Sensor(Optional) | Motion Sensor,Daylight Sensor |
| Emergency(Optional) | Available (30W @ 3Hrs for Standard) |
| Protection Class | ClassⅠ |
| Finishing Color(Optional) | Black RAL9017(Standard) |
| Material | Aluminum+PC |
| Lifespan/hrs | 70.000 Hrs (Ta=30℃@L70) |
| Operation Temp/℃ | 40°C to + 50°C(-40°F to 122°F) |
| Storage Temp/℃ | - 40°C to + 65°C(-40°F to 149°F) |
| Installation(Optional) | Loop Hanging, Ceiling Mounting, Wall Mounting |
| Certificate | CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available |
Shipment
Note: (1) For small order, express will be best.
(2) For bulk order, ship by sea or train(Europe destination) is the
best, but take much time.
(3) For urgent orders, we suggest via air to airport plus our ship
partner send to your door.
FAQ
Q1: What are the applications of your linear High Bay light?
RE: Our linear High Bay light can be applied in train, bus station
and Office, workshop and warehouse, supermarket, exhibition center,
airport hall, underground garage etc.
Q2: What installations of linear high bay light?
RE: Suspending/Ceiling mounted/Adjustable installation for option.
Q3: Finished color?
RE: Standard colors: Black / White, other colors can be customized,
based on MOQ 50PCS.
Q4: Can we get support if we have our own market position?
RE: Please inform us your detailed mind on your market demand. We
will discuss and propose helpful suggestion for you to find the
best solution for you.
Q5. What’s the meaning of “Beam Angle “?
RE: The spread of light from a luminaire. For example: a fitting
such as a low bay, which is closer to the floor, will have a wider
beam angle to illuminate a given floor area while a high bay
fitting will have a narrower beam.
Welcome to contact us for more information.
Let's meet DUALRAYS from below pictures!
Why DUALRAYS?
* Professional team: >10 years experience, own factory, >10 engineers team,
powerful production capacity and QC management system, provide both
good quality product and service;
* Reliable brand: Built up stable and long-term cooperation with Europe customers,
got high prise and trust, and have warehouse in Netherlands for
better service;
* Provide DIALux simulation: Send us your parameters of the applications, like distance,
height, width, etc, our engineer team will do simulation according
to your demand and recommend you the best product;
* All our LED luminaries comply with CE, RoHS standard. TUV, ENEC, VDE, SAA,C-Tick, LM79,LM80 listed for the leading
products.
ISO9001:2008 ISO14001:2004
The best quality innovation award Shenzhen Hi-tech Enterprise
Thank you for your using Dualrays LED luminaires, we regards
quality first as our marketing philosophy from the design and
package of all our products,we here declare that all of our products are tested by
professionals and obey strict quality standards,we have
professional after-sale service team to follow our customers,we promise that when you find
any quality problems caused by the products quality itself within
its guarantee period,you can contact us freely. When confirmed by the
QC Department, we will immediately help you to exchange or maintain products for free.Shenzhen Dualrays Optoelectronics Co.,
LIMITED. will serve you with heart and soul!
