Brand Name : | DUALRAYS |
Model Number : | DR-HB100-GGXP |
Certification : | CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available |
Price : | Negotiated |
Payment Terms : | L/C, T/T, Western Union |
Supply Ability : | 100000pcs/month |
Delivery Time : | 5-15 business days |
Model No. | DR-HB100-BHGXP | DR-HB150-BHGXP | DR-HB200-BHGXP |
System Watts/W | 100W | 150W | 200W |
System Efficiency/LPW | 140LPW / 160LPW Optional | ||
Lumen Output/lm | 14.000 / 16.000±5% | 21.000 / 24.000±5% | 28.000 / 32.000±5% |
Rated Input Voltage/V | AC100~277V, 50/60Hz | ||
LEDs Light Source | SMD2835 (1W) | ||
SDCM | <5 | ||
CCT/K | 5000K for Standard (3000K/4000K/5700K/6500K Optional) | ||
CRI/Ra | >70Ra (>80Ra for Option) | ||
Power Factor | >0.95 | ||
THD | <10% | ||
Beam Angle(Optional) | 60°/90°/120° Optional | ||
UGR | <25 | ||
Surge Protection | 3.75~4KV SPD built in Driver | ||
LED Driver | DUALRAYS Own-developed High PF Non-isolated Driver | ||
IP Rating | IP65 | ||
Dimming(Optional) | 0/1-10V/Zigbee | ||
Sensor(Optional) | Motion Sensor,Daylight Sensor | ||
Emergency(Optional) | Available (30W @ 3Hrs for Standard) | ||
Protection Class | ClassⅠ | ||
Finishing Color(Optional) | Black RAL9017(Standard) / White RAL9016 Optional | ||
Material | Aluminum+PC (Toughened Glass Cover Optional) | ||
Lifespan/hrs | 56.000 Hrs (Ta=30℃@L70) | ||
Operation Temp/℃ | 40°C to + 50°C(-40°F to 122°F) | ||
Storage Temp/℃ | - 40°C to + 65°C(-40°F to 149°F) | ||
Installation(Optional) | Loop Hanging, Ceiling Mounting, Wall Mounting | ||
Certificate | CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available |
Packaging Information
Shipment
Note: For small order,express will be best.And for bulk order,ship by
sea or train(Europe destination) is the best,but take much
time.For urgent orders,we suggest via air to airport plus our ship
partner send to your door.
Why DUALRAYS?
* Reliable brand: Built up stable and long-term cooperation with Europe customers, got high prise and trust, and have warehouse in Netherlands for better service;
* Provide DIALux simulation: Send us your parameters of the applications, like distance, height, width, etc, our engineer team will do simulation according to your demand and recommend you the best product;
* All our LED luminaries comply with CE, RoHS standard. TUV, ENEC, VDE, SAA,C-Tick, LM79,LM80 listed for the leading products.
