    Full Plastic Housing LED Tri Proof Light IP66 IK10 20W 120 Or 160LPW Easy Wiring

    Ask Lasest Price
    Brand Name : DUALRAYS(OEM available)
    Model Number : DR-TP030-BHG4XPX
    Certification : CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
    Price : Please inquiry for latest price
    Payment Terms : L/C, T/T, Western Union, paypal
    Supply Ability : 100000pcs/month
    Delivery Time : 5-15 bussiness days
    • Product Details
    • Company Profile

    Full Plastic Housing LED Tri Proof Light IP66 IK10 20W 120 Or 160LPW Easy Wiring

    Dualrays industrial lighting fixture D2.5 Series 2ft/20W LED Tri-proof Light 160LPW Efficiency 5 years guarantee emergency 0-10V and DALI dimming optional


    > Highly brightness EPISTAR/SAN‘AN SMD2835 LEDs,energy efficient - up to 160 lm/w;
    > 1-10V dimming flicker-free driver,DIP Switch Power Adjustment available,CCT adjustable available;
    > Single or Double wiring,backside cable output avaialable;
    > IP65 and IK08 for all industrial areas of application;
    > 2 in 1 design concept,integrated PC cover and PCBA,seperated housing,convenient installation,labor cost saving;
    > Multiple Link with double wiring;
    > No UV or IR and completely mercury free;
    > L80/B10 @ 50.000h;
    > 5 years warranty;

    Options:
    > Driver: DUALRAYS Own-developed flicker-free driver,BOKE DIP switch power adjustable driver.
    > Controls and Dimming: Zigbee wireless control / 1-10V Dimming / Daylight sensor,microwave sensor,CCTadjustable,emergency.
    > Plug : European / Australia plug with 0.75mm2/1.5mm2/2.5mm2 3-pins or 5-pins (dimming) cable optional.
    > Installation: Suspension.
    > Single or double wiring and connection.
    > Customized supported for special projects.
    * Replacement for fluorescent NCF
    * Workshops and warehouse
    * Garage and car parks
    * Sport facility
    * Corridor/Gallery/Corridor
    * Outdoor & Indoor Locations







    DALI Device


    DALI Intelligent Control Diagram


    DALI Intelligent Control Operator Interface


    Packaging Information


    Shipment

    Note: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much
    time.For urgent orders,we suggest via air to airport plus our ship partner send to your door.


    Q1: What is the warranty?
    RE: For the D5 Series LED triproof light,Dualrays provide 5 years warranty.If any quality problems on our side occured in this period ,we will take on the shipping cost and replacement.

    Q2: What is colour temperature?
    RE: Dualrays‘ LED lighting offer lamps in warm white, natural white,pure white and cool white with colour temperatures measured in Kelvin (K). The lower the colour temperature is,
    the warmer the light given by the LED:
    Warm white = 3000±200K
    Natural white = 4000±200K
    Pure white = 5000±200K
    Cool white = 5700±200K
    Q3: Is there a MOQ?
    RE: No MOQ, Sample order for testing welcome.

    Q4: What is the Lead time?
    RE: Normally 3-5 business days for samples, 10-15 business days for bulk orders.
    Q5: Can you do DIAlux Simulation?
    RE: We have professional DIAlux team to support you, IES files also can be downloaded on our Website.

    Q6: Do you offer mounting accessories?
    RE: Yes, please contact us for details.
    Q7: Do you offer OEM or ODM?
    RE: OEM and ODM service with customers‘ label is available,various choice for the package as below:
    1. We can provide you with our present products with your own label;
    2. We can modify our products as your request;
    3. We can even develop totally new products based on your design;
    Q8: What‘re the chips and drivers used?
    RE: High brightness San‘an SMD2835 LEDs light source,BOKE flicker free drivers for standard configuration.

    Q9: What is the CRI?
    RE: Ra>80 for standard.
    Q10: IP Rating?
    RE: IP65.

    Q11: Labeling ?
    RE: Neutral labeling/ Custom designed labels / Laser printing labels (at request).

    Q12: Finish color?
    RE: Standard colors: Silver,other colors can be customized, based on MOQ 50PCS.

    Q13: Dimming functions?
    RE: PIR sensor,Emergency,1-10V,DALI,Microwave sensor is available.

    Q14: Is there cheap shipping cost to import to our country?
    RE: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much time.For urgent
    orders,we suggest via air to airport plus our ship partner send to your door.

    Q15:Can we get support if we have our own market position?
    RE: Please inform us your detailed mind on your market demand,we will discuss and propose helpful suggestion for you,to find the best solution for you.

    Welcome to contact us for more information.
