    Waterproof 20w 30w 40w 50w 150lpw LED Tri Proof Vapour Light Fixture Panel

    Ask Lasest Price
    Brand Name : Dualrays
    Model Number : DR-TP020- CG2XP
    Certification : CE ROHS SAA
    Price : negotiate
    Payment Terms : T/T, Western Union
    Supply Ability : 50000 per month
    Delivery Time : 5-8work days
    • Product Details
    • Company Profile

    Waterproof 20w 30w 40w 50w 150lpw LED Tri Proof Vapour Light Fixture Panel

    Waterproof 20w 30w 40w 50w 150lpw LED Tri Proof Light Fixture Panel


    Dualrays D2 Waterproof Lighting 20w 30w 40w 50w 150lpw Triproof Light Led Fixture Panel Lighting Ce Rohs Saa

    > BASELine Version:

    > PROLine Version: 120(Milky Cover)~130LPW(Transparent Cover)

    > PRIMELine Version: 150(Milky Cover)~160LPW(Transparent Cover)

    >High Brightness SAN'AN SMD2835 LEDs,BOKE High PF Flicker-free Driver DIP Switch Power Adjustment Optional;

    > Against Water Pressure of 100bar(1450psi) and Temperature of 80°C;

    > IP69K PMMA IK06 Anti-ammonia/UV /PC IK10 Anti-UV Protection;

    > 120°beam angle;


    > Single or Double Wiring Optional,Linkabkle Thorugh Double End Wiring;

    > Multiple Installations: Suspension, Wall Mounting;

    > Various intelligent control: 1-10V, DALI, Motion sensor,Daylight sensor,

    > 304/316 Stainless Steel End Cap & Bracket,corrosion-proof;

    > No UV or IR and completely mercury free;

    > L70/B20 @ 54.000h;

    > Customized supported for special projects;

    > SAN'AN SMD2835 LEDs: LM80/TM-21 Available;

    > LM79/TM21/ISTMT/LCP and IES/LDT files available;

    (D6 LED Triproof Light)

    > Europe Market: CE(EMC+LVD),RoHS,TUV/GS,CB Pending,D-Mark;

    > North American Market: ETL/CETL,DLC Premium Pending;

    > Oceania Market: SAA,C-Tick,RCM

    #Led Top 10 Brand,A leading led light supplier

    Model No.DR-TP020-BG2XPXDR-TP030-BG4XPXDR-TP040-BG4XPXDR-TP040-BG5XPXDR-TP050-BG5XPX
    System Watts/W20W30W40W40W50W
    System Efficiency/LPW120LPW / 140LPW Optioanl
    Lumen Output/lm2.400/2.800±5%3.600/4.200±5%4.800/5.600±5%4.800/5.600±5%6.000/7.000±5%
    Rated Input Voltage/VAC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional)
    LEDs Light SourceSMD2835
    SDCM<6
    CCT/K5000K for Standard (3000K/4000K/5700K/6500K Optional)
    CRI/Ra>80Ra (>70Ra for Option)
    Power Factor>0.94
    THD<10%
    Beam Angle(Optional)120°
    UGR<22
    LED DriverDUALRAYS Own Developed High PF Interior Driver
    IP RatingIP65
    IK LevelIK08
    Dimming(Optional)1-10V
    Sensor(Optional)No
    Emergency(Optional)No
    Protection ClassClassⅠ
    Finishing Color(Optional)White RAL9016 Optional
    MaterialPC+PC
    Lifespan/hrs50.000 Hrs (Ta=30℃@L70)
    Operation Temp/℃40°C to + 50°C(-40°F to 122°F)
    Storage Temp/℃- 40°C to + 65°C(-40°F to 149°F)
    Installation(Optional)Suspension / Ceiling Mounting Optional
    CertificateCE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available
