    Integrated Circuit IP66 Round SMD LED Floodlight For Tennis Court IP65

    Ask Lasest Price
    Brand Name : DUALRAYS
    Model Number : DR-FL050-CG2
    Certification : CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 50000PCS/Month
    Delivery Time : 5-15 Bussiness Day
    • Product Details
    • Company Profile

    Integrated Circuit IP66 Round SMD LED Floodlight For Tennis Court IP65

    Integrated Circuit IP66 Round SMD LED Floodlight For Tennis Court


    Integrated Circuit Relay 500w For Tennis Court 5 Years Warranty Led Sport Ground 1000w Round Flood Light


    Model No.
    DR-FL050-CGXXDR-FL100-CGXXDR-FL150-CGXXDR-FL200-CGXXDR-FL300-CGXX
    System Watts/W
    50W100W150W200W
    300W
    System Efficiency/LPW
    120~125LPW
    Lumen Output/lm
    6.500±5%12.500±5%18.750±5%25.000±5%37.500±5%
    Rated Input Voltage/V
    AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional)
    LEDs Light Source
    SMD3030
    SDCM
    <5
    CCT/K
    5000K for Standard (3000K/4000K/5700K/6500K Optional)
    CRI/Ra
    >70Ra (>80Ra for Option)
    Power Factor
    >0.95
    THD
    <10%
    Beam Angle(Optional)
    Symmetrical 30°/60°/90°/120°,Asymmetrical/Type II / Type III / Type IV beam angle optional
    UGR
    <25
    Surge Protection
    6~10KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional
    LED Driver
    Sosen,Meanwell ELG / HLG Optional
    IP Rating
    IP65
    Dimming(Optional)
    1-10V, DALI,PWM,Zigbee for Option
    Safety ProtectionOpen Circuit / Short Circuit / Over-voltage / Over Temperature Protection
    Sensor (Optional)Motion Sensor
    Protection Class
    ClassⅠ
    Finishing Color(Optional)
    Black RAL9017(Standard) / White RAL9016 Optional
    Material
    Aluminum+Toughened Glass
    Lifespan/hrs
    62.000 Hrs (Ta=30℃@L70)
    Operation Temp/℃
    40°C to + 50°C(-40°F to 122°F)
    Storage Temp/℃
    - 40°C to + 65°C(-40°F to 149°F)
    Switching Cycles100,000 Times
    Certificate
    CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available

    > Precision Integrated Die-casting ADC12 AL,Excellent Thermal Conductivity;

    > High Brightness LUMILEDS LUXEON SMD3030 2D LEDs, SOSEN/Meanwell ELG/HLG Driver;

    > Built-in Plug and Play Motion Sensor with Compact Structure;

    > IP65 / IK10 Protection;

    > L70/B20 @ 62.000h;


    Application

    > Airports & Harbors

    > Billboard illumination

    > Large recreational sports facilities

    > Industrial areas & Landscape buildings

    > Roundabouts and motorway junctions

    Durable Dust Proof Led Lights Vapor Proof Led Light BOKE Driver AC 100~277V

    > Airports & Harbors
    > Billboard illumination
    > Large recreational sports facilities
    > Industrial areas & Landscape buildings
    > Roundabouts and motorway junctions
