5ft 50W LED Tri Proof Light Replacement Of 36W Fluorescent Full PC Housing Level IK10

DUALRAYS LIGHTING Co.,LTD.
Contact Now
    Buy cheap 5ft 50W LED Tri Proof Light Replacement Of 36W Fluorescent Full PC Housing Level IK10 from wholesalers

    Buy cheap 5ft 50W LED Tri Proof Light Replacement Of 36W Fluorescent Full PC Housing Level IK10 from wholesalers
    • Buy cheap 5ft 50W LED Tri Proof Light Replacement Of 36W Fluorescent Full PC Housing Level IK10 from wholesalers
    • Buy cheap 5ft 50W LED Tri Proof Light Replacement Of 36W Fluorescent Full PC Housing Level IK10 from wholesalers
    • Buy cheap 5ft 50W LED Tri Proof Light Replacement Of 36W Fluorescent Full PC Housing Level IK10 from wholesalers
    • Buy cheap 5ft 50W LED Tri Proof Light Replacement Of 36W Fluorescent Full PC Housing Level IK10 from wholesalers

    5ft 50W LED Tri Proof Light Replacement Of 36W Fluorescent Full PC Housing Level IK10

    Ask Lasest Price
    Brand Name : DUALRAYS
    Model Number : DR-TPL050-BG5X
    Certification : CE,RoHS,TUV/GS,LM79,LM80
    Price : Negotiable
    Delivery Time : 5-15 business days
    Supply Ability : 100,000PCS/Month
    • Product Details
    • Company Profile

    5ft 50W LED Tri Proof Light Replacement Of 36W Fluorescent Full PC Housing Level IK10

    5ft 50W LED Tri Proof Light Replacement Of 36W Fluorescent Full Pc Housing Level IK10

    LED Tri Proof Light Feature:

    * Luminaire coated in an environmentally friendly polyester powder formulated in a silvery,black and white finish;

    * No toxic heavy metals, VOC, or mercury were used in the design;

    * 120LPW Proline Version,150LPW Primeline Version for option,CRI>80Ra,more sufficient;

    * 270°adjustable European Bracket for actual lighting direction;

    * Controls and Dimming: Zigbee wireless control / 1-10V Dimming / Daylight sensor,microwave sensor,CCTadjustable,emergency.

    * Plug : European / Australia plug with 0.75mm2/1.5mm2/2.5mm2 3-pins or 5-pins (dimming) cable optional.


    ItemSymbol2ft/20W4ft/40W5ft/50W
    Model No/DR-TPL020-BG21DR-TPL040-BG41DR-TPL050-BG51
    Rated PowerW204050
    LEDs Typ/Qty

    SMD

    2835

    144PCS273PCS312 PCS
    Luminous Flux

    Clear

    Frost

    3,200±5%

    3,000±5%

    6,400±5%

    6,000±5%

    8,000±5%

    7,500±5%

    Efficiency

    Clear

    Frost

    Typ.160

    Typ.150

    Typ.160

    Typ.150

    Typ.160

    Typ.150

    Lumen Maintenance @ 6000 hrsHours>80%
    Switching Cycle before FailureTimes100,000
    Life SpanHours50,000
    WarrantyYears3 years
    Operation Temperature-15 ~ +50℃
    Storage Temperature-25 ~ +55℃

    DUALRAYS R&D team including:
    * Electronic engineer
    * Packing design engineer
    * Structural engineer
    * Sample testing engineer
    * Heat management design engineer
    DUALRAYS gathers a group of managers and technical personnel who have been working in the LED industry for many years as a key role. Involving majors:physical, thermal, optical, mechanical, electronic and so on.
    Multi-disciplinary talents lay a solid foundation for the development of our company.
    Durable Dust Proof Led Lights Vapor Proof Led Light BOKE Driver AC 100~277V
    Durable Dust Proof Led Lights Vapor Proof Led Light BOKE Driver AC 100~277V
    * Replacement for fluorescent NCF
    * Workshops and warehouse
    * Garage and car parks
    * Sport facility
    * Corridor/Gallery/Corridor
    * Outdoor & Indoor Locations
    Model No.DR-TP020-EG2XPXDR-TP040-EG4XPXDR-TP050-EG4XPXDR-TP060-EG5XPXDR-TP080-EG5XPX
    System Watts/W20W40W50W60W
    80W
    System Efficiency/LPW130LPW / 160LPW Optioanl
    Lumen Output/lm2.600/3.200±5%5.200/6.400±5%6.500/8.000±5%7.800/9.600±5%10.400/12.800±5%
    Rated Input Voltage/VAC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional)
    LEDs Light SourceSMD2835
    SDCM<6
    CCT/K5000K for Standard (3000K/4000K/5700K/6500K Optional)
    CRI/Ra>80Ra (>70Ra for Option)
    Power Factor>0.91
    THD<10%
    Beam Angle(Optional)120°
    UGR<22
    LED DriverBOKE Fixed Power/ DIP Switch Power Adjustable Optional
    IP RatingIP65
    IK LevelIK08
    Dimming(Optional)1-10V, DALI,Zigbee
    Sensor(Optional)Daylight sensor/Microwave Sensor
    Emergency(Optional)5W@3 Hours or Customized
    Protection ClassClassⅠ
    Finishing Color(Optional)White RAL9016 Optional
    MaterialAL+PC
    Lifespan/hrs62.000 Hrs (Ta=30℃@L70)
    Operation Temp/℃40°C to + 50°C(-40°F to 122°F)
    Storage Temp/℃- 40°C to + 65°C(-40°F to 149°F)
    Installation(Optional)Suspension / Ceiling Mounting Optional
    CertificateCE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available

    Durable Dust Proof Led Lights Vapor Proof Led Light BOKE Driver AC 100~277V


    Durable Dust Proof Led Lights Vapor Proof Led Light BOKE Driver AC 100~277V
    Durable Dust Proof Led Lights Vapor Proof Led Light BOKE Driver AC 100~277V
    Durable Dust Proof Led Lights Vapor Proof Led Light BOKE Driver AC 100~277V
    (I) Emergency Function
    Durable Dust Proof Led Lights Vapor Proof Led Light BOKE Driver AC 100~277V

    Durable Dust Proof Led Lights Vapor Proof Led Light BOKE Driver AC 100~277V
    Durable Dust Proof Led Lights Vapor Proof Led Light BOKE Driver AC 100~277V

    Durable Dust Proof Led Lights Vapor Proof Led Light BOKE Driver AC 100~277V
    Durable Dust Proof Led Lights Vapor Proof Led Light BOKE Driver AC 100~277V
    Full Plastic Housing LED Tri Proof Light IP66 IK10 20W 120/160LM/W 3000K-6500K
    Note: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much
    time.For urgent orders,we suggest via air to airport plus our ship partner send to your door.


    Full Plastic Housing LED Tri Proof Light IP66 IK10 20W 120/160LM/W 3000K-6500K

    Q1.How do we explain “CRI” ?

    RE: A measure of the degree of colour shift objects undergo when illuminated by the light source as compared with those same objects when illuminated by a reference source of comparable colour temperature. The reference source has a CRI of 100.


    Q2.Do you know “dali “?

    RE: Digital addressable lighting interface (DALI) is a trademark for network-based systems that control lighting in building automation.


    Q3.Why we use the high power LED ?

    RE: A high power LED, sometimes referred to as a power LED, is one that is driven at current of 350mA or higher.


    Q4.What’s LED Chips ?

    RE: The light producing semiconductor device that may or may not be incorporated into an LED.


    Q5.What’s Smart Lighting ?

    RE: Automated lighting control using sensors and /or scheduling switches.


    Q6. How is your production capacity?

    RE: Our output value is 10 million USD
