200W IP66 Protection Modular LED Floodlight Mutiple Beam Angle for Different Application

DUALRAYS LIGHTING Co.,LTD.
Contact Now
    Buy cheap 200W IP66 Protection Modular LED Floodlight Mutiple Beam Angle for Different Application from wholesalers

    Buy cheap 200W IP66 Protection Modular LED Floodlight Mutiple Beam Angle for Different Application from wholesalers
    • Buy cheap 200W IP66 Protection Modular LED Floodlight Mutiple Beam Angle for Different Application from wholesalers
    • Buy cheap 200W IP66 Protection Modular LED Floodlight Mutiple Beam Angle for Different Application from wholesalers

    200W IP66 Protection Modular LED Floodlight Mutiple Beam Angle for Different Application

    Ask Lasest Price
    Brand Name : DUALRAYS
    Model Number : DR-FL200-CGXX
    Certification : CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
    Price : Negotiable
    Delivery Time : 5-15 Bussiness Day
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 50000PCS/Month
    • Product Details
    • Company Profile

    200W IP66 Protection Modular LED Floodlight Mutiple Beam Angle for Different Application


    Options:
    > Driver: Sosen,Meanwell ELG/HLG driver;
    > Controls and Dimming: 1-10V, DALI,PWM,Zigbee;
    > Surge Protection Device: Meanwell SPD-20 20KV Surge Protector;
    > Lens : Symmetrical 30°/60°/90°/120°,Asymmetrical/Type II / Type III / Type IV;
    > Microwave Motion Sensor;

    > Airports & Harbors
    > Billboard illumination
    > Large recreational sports facilities
    > Industrial areas & Landscape buildings
    > Roundabouts and motorway junctions

    Model No.
    DR-FL050-CGXXDR-FL100-CGXXDR-FL150-CGXXDR-FL200-CGXXDR-FL300-CGXX
    System Watts/W
    50W100W150W200W
    300W
    System Efficiency/LPW
    120~125LPW
    Lumen Output/lm
    6.500±5%12.500±5%18.750±5%25.000±5%37.500±5%
    Rated Input Voltage/V
    AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional)
    LEDs Light Source
    SMD3030
    SDCM
    <5
    CCT/K
    5000K for Standard (3000K/4000K/5700K/6500K Optional)
    CRI/Ra
    >70Ra (>80Ra for Option)
    Power Factor
    >0.95
    THD
    <10%
    Beam Angle(Optional)
    Symmetrical 30°/60°/90°/120°,Asymmetrical/Type II / Type III / Type IV beam angle optional
    UGR
    <25
    Surge Protection
    6~10KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional
    LED Driver
    Sosen,Meanwell ELG / HLG Optional
    IP Rating
    IP65
    Dimming(Optional)
    1-10V, DALI,PWM,Zigbee for Option
    Safety ProtectionOpen Circuit / Short Circuit / Over-voltage / Over Temperature Protection
    Sensor (Optional)Motion Sensor
    Protection Class
    ClassⅠ
    Finishing Color(Optional)
    Black RAL9017(Standard) / White RAL9016 Optional
    Material
    Aluminum+Toughened Glass
    Lifespan/hrs
    62.000 Hrs (Ta=30℃@L70)
    Operation Temp/℃
    40°C to + 50°C(-40°F to 122°F)
    Storage Temp/℃
    - 40°C to + 65°C(-40°F to 149°F)
    Switching Cycles100,000 Times
    Certificate
    CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available

    Character/Power
    100W
    150W
    200W
    240W
    300W
    A / mm
    389
    389
    437
    493
    582
    B / mm
    297
    297
    346
    379
    444
    C / mm
    57
    57
    57
    57
    60















    Model No.
    Net Weight/Kg
    Outer Carton Size/mm
    Gross Weight/Kg
    QTY”/CTN
    DR-FL050-CGXX
    3.6
    355*350*165
    4.5
    1PCS/CTN
    DR-FL100-CGXX
    3.8
    355*350*165
    4.7
    1PCS/CTN
    DR-FL150-CGXX
    4.5
    415*410*175
    5.8
    1PCS/CTN
    DR-FL200-CGXX
    5.7
    475*470*195
    7.3
    1PCS/CTN
    DR-FL300-CGXX
    9.3
    475*470*195
    11.5
    1PCS/CTN







    Dualrays 50W Aluminium Housing LED Flood Light IP66 Waterproof With Adjustable Beam Angle

    Q1: What is the warranty for the F4 LED Flood Light?
    RE: For the F4 Series LED flood light,Dualrays provide 5 years warranty.If any quality problems on our side occured in this period ,we will take on the shipping cost and replacement.

    Q2: What is colour temperature?
    RE: Dualrays‘ LED lighting offer lamps in warm white, natural white,pure white and cool white with colour temperatures measured in Kelvin (K). The lower the colour temperature is,
    the warmer the light given by the LED:
    Warm white = 3000±200K
    Natural white = 4000±200K
    Pure white = 5000±200K
    Cool white = 5700±200K
    Q3: Is there a MOQ?
    RE: 2PCS

    Q4: What is the Lead time?

    RE: Normally 3-5 business days for samples, 10-15 business days for bulk orders.


    Q5: Can you do DIAlux Simulation?
    RE: We have professional DIAlux team to support you, IES files also can be downloaded on our Website.

    Q6: Do you offer mounting accessories?

    RE: Yes, please contact us for details.


    Q7: Do you offer OEM or ODM?
    RE: OEM and ODM service with customers‘ label is available,various choice for the package as below:
    1. We can provide you with our present products with your own label;
    2. We can modify our products as your request;
    3. We can even develop totally new products based on your design;
    Q8: What‘re the chips and drivers used?
    RE: High brightness San‘an SMD2835 LEDs light source,flicker free drivers for option.
