High Efficiency Outdoor LED Street Lights With 60W IP66 IK10

Outdoor LED Street lights Production details:

Why choosing DUALRAYS:

* Reliable brand: Built up stable and long-term cooperation with Europe customers, got high prise and trust, and have warehouse in Netherlands for better service;

* Provide DIALux simulation: Send us your parameters of the applications, like distance, height, width, etc, our engineer team will do simulation according to your demand and recommend you the best product;

* All our LED luminaries comply with CE, RoHS standard. TUV, ENEC, VDE, SAA,C-Tick, LM79,LM80 listed for the leading products.

2020 Top sae Heat Dissipation Cobra Led Street Light IK10 Vibration Grade 180W 10KV / 20KV SPD IP66 with motion sensor

Outdoor LED Street Lights Production sepecification:

> High brightness LUXEON SMD3030 LEDs,energy efficient - up to 150 lm/w;

> Die-casting Al for excellent heat dissipation;

> Superior PC reflector-optic for low glare applications,and toughened glass protection;

> IP66 and IK10 for road lighting application;

> Driver and housing separated by spacers;

> Professional 50(V)*120(H)°/75(V)*150°(H) optic for option;

> ±10°/-90°(<90W) or ±15°/-90°(>90W) lamp head adjustable;

> No UV or IR and completely mercury free;

> L80/B10 @ 50.000h;

> Controls and Dimming: 1-10V, DALI, PWM,Zigbee Wireless Dimming for option;

> 10KA SPD,20KA Meanwell SPD optional;

> 3-pins photocell controller ON/OFF,and 7-pins LORA/NEMA socket smart wireless control available;
> Zigbee module (Single-lamp Controller and centralized manager) with software for option;
> DALI driver and DALI Centralized Manager optional;
> Light pole adapter for different poles optional;

> Customized supported for special projects;

* Roadways.

* Avenues.

* Walkways.

* Loading Area.

* Parking lot.

* Playground.
* Sport and Stadium.

Item No.	DR-ST60-DGXP	Housing color	Silver, Black, Grey etc
Input Voltage	AC100-277V 50/60HZ	CRI	>80Ra(>70Ra for option)
Power	60W	IP Rating	IP66
Working Temp	-40 to +50℃	IK Rating	IK10
Luminous Flux	16,800lm	Material	AL+PMMA
Beam Angle	60*120º/75*135°	LED Efficiency	150LPW
CCT	2700-6500K	Certificate	CE, RoHS,
Dimension	950(L)*455(W)*125(D)mm	Warranty	5 years
UGR	<25	Driving Brand	Meanwell/Sosen

30W/60W Version

90W,120W/150W/180W Version

Zigbee Wireless Intelligent Control Operator Interface
