Dualrays Universal Retrofit LED Lights Module Plug and Play
| Item | Symbol | Description |
| Model No | / | DR-ULM035-DE5C |
| Length | mm | 1430 |
| Color | / | White RAL 9003 |
| LEDs source | / | SMD2835 |
| Driver | / | BOKE |
| Efficiency | LPW | 150 |
| Colo Temperature | CCT/K | WW:3000±200K NW: 4000±200K DW:5000±200K CW: 6000±200K |
| Dimming Function | / | DALI |
| Protections | / | Short circuit/Over current/Over voltage/Over temperature |
| Anti-salty spray | / | Grade A |
| Color Index | Ra | >80Ra |
| Beam Angle | Degree | 30°/60°/90°/120°/Double Asy 25°/Single Asy 25° |
| AC Input Vol | V | AC220-240V/DC180-264V |
| Output Vol | V | DC32V |
| Power Factor | PF | PF>0.95 |
| Lumen Maintenance @ 6000 hrs | Hours | >80% |
| Switching Cycle before Failure | Times | 100,000 |
| Life Span | Hours | 50,000 |
| Warranty | Years | 5 years |
| Operation Temperature | ℃ | -40 ~ +55℃ |
| Storage Temperature | ℃ | -40 ~ +85℃ |
Feature
a. Private Mold for PMMA Extrusion lens,much more durable and
elegant normal PC Injection lens in the market;
b. Plug and play, universal compatibiltity for Europe brands
Trunking rails.
c. BOKE flicker-free driver,with non-dimming,1-10V,DALI dimming,
AC/DC input; above only means linear module, extra function or
installationkits ,please contact us for quotation;
d. Customized dimming type or emergency function,please contact us
for confirmation;
Advantage
* Powerful production capacity and QC management system;
* Excellent experience for distributors, wholesales and contractor
from Western Europe and Oceania;
* All our LED liminaires comply with CE, RoHS standard. TUV, ENEC,
VDE, SAA,C-Tick, LM79,LM80 listed for the leading products;
* Supply different version with different configurations for our
customers.
* Provide Dialux software for lighting design project for our
customers;
* Have branch office and warehouse in Netherlands with more than
4000㎡. 3 days delivery time, fast reaction.
* Excellent experience for distributors, wholesales and contractor
from Western Europe and Oceania;
* Our service and products are recognized from famous enterprises
such as Jalasoft, Mercedes-Benz, Rewe, Nahkauf, Hagebau,etc.
Application
* Office
* Workshops and warehouse
* Supermarkets
* Underground parking
In addition,we can provide our customers value added service with
Dialux software for lighting design projects free of charge.
Notes:
(1) For small order,express will be best.
(2) For bulk order,ship by sea or train(Europe destination) is the
best,but take much time.
(3) For urgent orders,we suggest via air to airport plus our ship
partner send to your door.
FAQ
Q1: Does Dualrays have the ability to do independence and
development ?
RE: Our engineer department have 12 people. We have the research
and development capability. We also collect regularly each customer
feedback. We have product improvement and new product development.
Q2: LEDs are more expensive than other lighting options,why ?
RE: LEDs can operate as stand alone devices,but when grouped or
clustered they require additional steps to operate properly. LEDs
need proper components such as a circuits can be designed rapidly,
but to ensure that they operate correctly and for long periods of
time they require testing.
Q3.How to explain “Flux/luminous Flux “?
RE: Luminous flux is the measure of the perceived power of light
produced by the LED, adjusting to reflect the varying sensitivity
of the human eye to different wavelengths of light.
Q4.Why we use the high power LED ?
RE: A high power LED, sometimes referred to as a power LED, is one
that is driven at current of 350mA or higher.
Q5.How important is IP ?
RE: Classifies and rates the degree of protection provided against
intrusion (body parts such as hands and fingers), dust, accident
contact, and water by mechanical casing and electrical enclosures.
Q6.What’s LED Chips ?
RE: The light producing semiconductor device that may or may not be
incorporated into an LED.
ISO9001:2008 ISO14001:2004
